AHC MAKINE - CNC RAPID DRILLING 4014

Operating System:

Thanks to the TPA CAD software, it saves the drawing again and again . Once the drawing is finished , even if different parts appeared , When you just enter the dimensions of the new part, it automatically optimizes your previously prepared work and sets and adjusts the shifts , gabs , and even the number of holes needed

Technical Specifications :

Minimum width for the piece : 50 mm

Maximum width for the piece : 1300 mm

Automatic lubrication system

4 kw spindle motor power with 18000 RPM

Minimum length for the piece : 150 mm

Maximum length for the piece : unlimited

Machine speed : 60 m/min

Front and back vaccum table with penumatic system

Minimum Depth : 3 mm

Maximum Depth : 45 mm

Ability to work in 5 faces in 1 stroke

Drilling unit FAM BRAND

9 Vertical Drilling tools

6 Horizontal drilling tools

1 Blade Saw

Servo control unit for Axises X,Y,Z
